Automated Wine Transfer & Product Recovery Process Solution for Process Optimization
Project Overview
A family-owned wine bottling company from the Beaujolais wine district in France sought to automate its wine transfer processes for expansion while increasing efficiency, hygiene and product recovery.
The old process had to be replaced by an optimized process that would facilitate safe transfer of wine from tanks or tanker trucks while reducing product losses and protecting wine product quality.
The new process also had to integrate smoothly with the existing Clean-In-Place (CIP) process system.
The Challenge
With increased production needs, the winery required a more efficient and automated wine transfer process that could:
- Facilitate wine transfer from tanks and tanker trucks
- Limit product losses in the transfer process
- Safeguard the quality of the fragile wine products
- Be capable of handling multiple transfers
- Reduce labour requirement
- Be integrated with the existing CIP process system
- Meet high hygienic standards
- Provide reliable process control
The INOXPA Solution
INOXPA offered and supplied an automatic wine transfer system that included hygienic pumping, automation and product recovery technologies.
Three separate transfer lines were included in the design so as to be able to conduct operations either independently or jointly as per production demands.
SilPig product recovery system was used to recover any leftover wine from the pipeline, minimizing losses and increasing efficiency.
Key Equipment & Technologies
- 3 automatic transfer lines
- SilPig product recovery system
- 3 KIBER KSF-40 progressive cavity pumps
- Pumping rate of up to 4,500 Liters/hour @ 4 bar
- PLC automation with a 12-inch touchscreen
- VFD controlled pumping
- Conjunction with the existing CIP system
- Stainless steel skid with FDA components
Product Recovery with Sanitary Pigging
The one more important feature of the installation is its product recovery system.
There is always some amount of product remaining in the pipelines after the wine transfer by pumping. The sanitary pigging system allows recovering this product before the cleaning process starts.
This feature is especially useful for wineries, where the value of product, process and hygiene are essential.
Conclusions
Automated wine transfer system offered many operational benefits: Less Product Losses
Product recovery system allows recovering the residual wine in the pipelines, reducing the product loss during the process.
More Efficient Transfer
Three separate transfer lines allow alternative or parallel use of the process lines increasing efficiency.
Process Control
PLC system, touchscreens and variable frequency drives ensure centralized and local control over the transfer process.
Hygiene
Use of 316L stainless steel, hygienic finishing and proper sanitary components helps to comply with the high hygiene requirements of wine processing process.
Easy Integration with CIP System
The new equipment was designed with ability to easily connect to the existing CIP system without any significant modifications.
A Better Way to Manage Wine Handling
In this case study, you will see how appropriate application of sanitary pumps and product transfer and automation solutions can lead to increased efficiency at wineries without any additional waste.
The INOXPA transfer system offered to Maison Peguet included all of the necessary characteristics and was based on the special requirements of wine handling process.
